NEMA 23 (57mm) 3-Phase Bipolar Stepper Motor, 1.2° Step Angle, IP65 Waterproof

IP-rated waterproof bldc motor for outdoor and wet environment applications. (65W, 57mm) Get a free quote from ZGC Motors, a trusted servo motor manufacturer.

  • High Torque Output: Delivers a wide torque range of 0.8 to 3.2 Nm, ensuring robust performance at both high and low speeds.
  • Advanced Drive Technology: 3-phase bipolar design for smoother operation and higher torque density.
  • Reliable Protection: IP65 rating provides defense against dust and water jets, suitable for demanding environments.
  • Precise Positioning: 1.2° step angle enables accurate motion control.
  • Application: agricultural machine, fountain

Motor Specifications

ModelCurrentResistanceInductanceHolding torqueInertiaLengthWeight
AΩ±10%mH±20%N.mOZ.ing/cm²mm MaxKgLbs
SD57IP355-35043.50.771.81.0141.6280651.53.3
SD57IP355-55045.50.51.61.0141.6280651.53.3
SD57IP380-35043.50.861.21.8255.0480902.55.5
SD57IP380-55045.50.72.41.8255.0480902.55.5



Engineered for High-Torque Performance: This IP65 waterproof stepper motor delivers high torque (0.8-3.2 Nm) for demanding applications. Featuring a 3-phase bipolar design and 1.2° step angle for smooth, precise motion control.
