Max efficiency of gear box : 81%
Max permmissible torque : 40Nm
Motor power : 300-550W
Application : Robot
Max efficiency of gear box : 81%
Max permmissible torque : 40Nm
Motor power : 300-550W
Application : Robot
BRUSHLESS MOTOR SPECIFICATION
| TYPE | Rated
voltage |
No-load
speed |
Rated
speed |
Rated
torque |
Rated
power |
Rated current | Length |
| VDC | r/min | r/min | N.m | W | A | mm | |
| 86DMW80-4830 | 48 | 3500 | 3000 | 1.0 | 300 | 10.5 | 81 |
| 86DMW90-4830 | 48 | 3500 | 3000 | 1.3 | 400 | 13.8 | 91 |
| 86DMW100-4830 | 48 | 3500 | 3000 | 1.60 | 500 | 17.5 | 101 |
| 86DMW105-4830 | 48 | 3500 | 3000 | 1.8 | 550 | 19.6 | 106 |
SPUR GEAR BOX SPECIFICATION
| Number of gear trains | 1 | 2 | 3 | |
| Reduction ratio | 3/3.6/5/6/7.5/9/12.5/15/18 | 25/30/36 | 50/60/75/90/100/120/150/180/200 | |
| length | 72 | 72 | 72 |
