Max efficiency of gear box : 81%
Max permmissible torque : 3Nm
Motor power : 35-130W
Application : Gate system
Max efficiency of gear box : 81%
Max permmissible torque : 3Nm
Motor power : 35-130W
Application : Gate system
BRUSHLESS MOTOR SPECIFICATION
| TYPE |
Rated voltage |
No-load
speed |
Rated
speed |
Rated
torque |
Rated
power |
Rated current | Length |
| VDC | r/min | r/min | N.m | W | A | mm | |
| 57DMW55-2430 | 24 | 4200 | 3000 | 0.11 | 35 | 2.5 | 60 |
| 57DMW75-2430 | 24 | 4200 | 3000 | 0.22 | 69 | 4.8 | 80 |
| 57DMW95-2430 | 24 | 4200 | 3000 | 0.32 | 100 | 7 | 100 |
| 57DMW115-2430 | 24 | 4200 | 3000 | 0.42 | 132 | 9.2 | 120 |
SPUR GEAR BOX SPECIFICATION
| Number of gear trains | 1 | 2 | 3 |
| Reduction ratio | 3/3.6/5/6/7.5/9/12.5/15/18 | 25/30/36 | 50/60/75/90/100/120/150/180/200 |
| length | 32 | 42 | 42 |
