Max efficiency of gear box : 89%
Motor power : 60W
Application : AGV
Max efficiency of gear box : 89%
Motor power : 60W
Application : AGV
BLDC MOTORSPECIFICATION
| TYPE | Rated
voltage |
No-load
speed |
Rated
speed |
Rated
torque |
Rated
power |
Rated current | Length |
| VDC | rpm | rpm | N.m | W | A | mm | |
| 80DMW47-2430 | 24 | 3800 | 3000 | 0.19 | 60 | 3.6 | 47 |
L TYPE GEAR BOXSPECIFICATION
| Reduction ratio | 5 | 10 | 15 | 20 | 30 | 50 | 100 | 200 | |||||||
| Efficiency | 74% | 89% | |||||||||||||
| Rated speed | rpm | 600 | 300 | 200 | 150 | 100 | 60 | 30 | 15 | ||||||
| Rated Toqrue | Nm | 1.2 | 2.4 | 3.5 | 4.8 | 7 | 10 | 12 | 12 | ||||||
All gear box output turn direction in above form are opposite as motor direction
